The Bike Museum - Models

MV Magni » Magni Arturo 1994

Make	MV Magni
Model	Magni Arturo 1994
Capacity	948
Start Year	1987
End Year	2000
Bore Stroke	bore 88mm stroke 78
Engine Config	V
Number Of Cylinders	2
Engine Type	Four Stroke
Valves per Cylinder	2
Valve Operation	Pushrod
Power	63
Cooling	Air Cooled
Gears	5
Transmission	Shaft Drive
Weight	195
Front Wheel	10090 V 18
Rear Wheel	13080 V 18
Front Brake	Twin Disc
Rear Brake	Disc
Top Speed	230
Fuel Cons	6.00
Fuel Cap	17
Number Make	200
Engine Number Range	unknown
Frame Number Range	unknown
RPM	7500
Commpression Ratio	10
Carburettors	2 DellOrto PHM 40

Summary

Though not an MV with its Moto Guzzi Le Mans V Nuovo Tipo engine this is a real Magni.

After in 1976 MV pulled out of racing Arturo Magni founded his own firm and developed a small range of handcrafted motorcycles, starting by using the MV alike Honda 900 Bol dOr engine for the MH1 and MH2. The succes of these bikes in Germany led to the BMW driven MB series. Due to a lack of response to these bikes Magni turned to an all-Italian motorcycle and found Moto Guzzi as a partner.In the following years Magni built over 700 Magni Guzzis since the first Magni Le Mans in 1985. A feature is the Parallelogrammo rear end, eliminating the handling disadvantages of the shaft-driven transmission. With its hand-made chrome-moly tubular frame, its fairing and all Italian components the Magni Arturo is a tribute to the earlier MVs.
